Deploy Service#

This guide provides step-by-step instructions for deploying OSMO service components on a Kubernetes cluster.

Components Overview#

OSMO deployment consists of several main components:

Component

Description

API Service

Workflow operations and API endpoints

Router Service

Routing traffic to the API Service

Web UI Service

Web interface for users

Worker Service

Background job processing

Logger Service

Log collection and streaming

Agent Service

Client communication and status updates

Delayed Job Monitor

Monitoring and managing delayed background jobs
../../_images/service_components.svg

Step 1: Configure PostgreSQL#

Create a database for OSMO using the following command. Omit export OSMO_PGPASSWORD=... and PGPASSWORD=$OSMO_PGPASSWORD if PostgreSQL was configured without a password.

$ export OSMO_DB_HOST=<your-db-host>
$ export OSMO_PGPASSWORD=<your-postgres-password>
$ kubectl apply -f - <<EOF
apiVersion: v1
kind: Pod
metadata:
  name: osmo-db-ops
spec:
  containers:
    - name: osmo-db-ops
      image: alpine/psql:17.5
      command: ["/bin/sh", "-c"]
      args:
        - "PGPASSWORD=$OSMO_PGPASSWORD psql -U postgres -h $OSMO_DB_HOST -p 5432 -d postgres -c 'CREATE DATABASE osmo;'"
  restartPolicy: Never
EOF

Check that the process Completed with kubectl get pod osmo-db-ops. Then delete the pod with:

$ kubectl delete pod osmo-db-ops

Step 2: Create namespace and secrets#

Before creating secrets, register OSMO as an OAuth2/OIDC application in your identity provider and obtain the client ID, client secret, and endpoints (token, authorize, JWKS, issuer). See Identity Provider (IdP) Setup for provider-specific steps.

Create a namespace to deploy OSMO:

$ kubectl create namespace osmo

Create secrets for the database and Redis:

$ kubectl create secret generic db-secret --from-literal=db-password=<your-db-password> --namespace osmo
$ kubectl create secret generic redis-secret --from-literal=redis-password=<your-redis-password> --namespace osmo

Create the secret used by OAuth2 Proxy for the client secret and session cookie encryption. Use the client secret from your IdP application registration:

$ kubectl create secret generic oauth2-proxy-secrets \
  --from-literal=client_secret=<your-idp-client-secret> \
  --from-literal=cookie_secret=$(openssl rand -base64 32) \
  --namespace osmo

Create the master encryption key (MEK) for database encryption:

  1. Generate a new master encryption key:

    The MEK should be a JSON Web Key (JWK) with the following format:

    {"k":"<base64-encoded-32-byte-key>","kid":"key1","kty":"oct"}

  2. Generate the key using OpenSSL:

    # Generate a 32-byte (256-bit) random key and base64 encode it
$ export RANDOM_KEY=$(openssl rand -base64 32 | tr -d '\n')

# Create the JWK format
$ export JWK_JSON="{\"k\":\"$RANDOM_KEY\",\"kid\":\"key1\",\"kty\":\"oct\"}"

  3. Base64 encode the entire JWK:

    $ export ENCODED_JWK=$(echo -n "$JWK_JSON" | base64 | tr -d '\n')
$ echo $ENCODED_JWK

  4. Create the ConfigMap with your generated MEK:

    $ kubectl apply -f - <<EOF
apiVersion: v1
kind: ConfigMap
metadata:
  name: mek-config
  namespace: osmo
data:
  mek.yaml: |
    currentMek: key1
    meks:
      key1: $ENCODED_JWK
EOF

Warning

Security Considerations:

  • Store the original JWK securely as you’ll need it for backups and recovery

  • Never commit the MEK to version control

  • Use a secure key management system, such as Vault or secrets manager in production

  • The MEK is used to encrypt sensitive data in the database

Example MEK generation script:

#!/bin/bash
# Generate MEK for OSMO

# Generate random 32-byte key
$ export RANDOM_KEY=$(openssl rand -base64 32 | tr -d '\n')

# Create JWK
$ export JWK_JSON="{\"k\":\"$RANDOM_KEY\",\"kid\":\"key1\",\"kty\":\"oct\"}"

# Base64 encode the JWK
$ export ENCODED_JWK=$(echo -n "$JWK_JSON" | base64 | tr -d '\n')
$ echo "Encoded JWK: $ENCODED_JWK"

# Create ConfigMap
$ kubectl apply -f - <<EOF
apiVersion: v1
kind: ConfigMap
metadata:
  name: mek-config
  namespace: osmo
data:
  mek.yaml: |
    currentMek: key1
    meks:
      key1: $ENCODED_JWK
EOF

Step 3: Prepare values#

Create a values file for each OSMO component.

See also

See Identity Provider (IdP) Setup for the IdP-specific values you need to configure (client ID, endpoints, JWKS URI) and Authentication Flow for the request flow.

Create osmo_values.yaml for the OSMO service with the following sample. Configure the oauth2Proxy, jwt providers, and services.service.auth sections with your IdP’s endpoints and client ID:

osmo_values.yaml
# Global configuration shared across all OSMO services
global:
  osmoImageLocation: nvcr.io/nvidia/osmo
  osmoImageTag: <version>
  serviceAccountName: osmo

  logs:
    enabled: true
    logLevel: DEBUG
    k8sLogLevel: WARNING

# Individual service configurations
services:
  # Configuration file service settings
  configFile:
    enabled: true

  # PostgreSQL database configuration
  postgres:
    enabled: false
    serviceName: <your-postgres-host>
    port: 5432
    db: <your-database-name>
    user: postgres

  # Redis cache configuration
  redis:
    enabled: false  # Set to false when using external Redis
    serviceName: <your-redis-host>
    port: 6379
    tlsEnabled: true  # Set to false if your Redis does not require TLS

  # Main API service configuration
  service:
    scaling:
      minReplicas: 1
      maxReplicas: 3
    hostname: <your-domain>
    auth:
      enabled: true
      device_endpoint: <idp-device-auth-url>
      device_client_id: <client-id>
      browser_endpoint: <idp-authorize-url>
      browser_client_id: <client-id>
      token_endpoint: <idp-token-url>
      logout_endpoint: <idp-logout-url>

  # Default admin (no IdP): enable to create an admin user and access token at startup
  defaultAdmin:
    enabled: false  # Set true when not using an IdP
    username: "admin"
    passwordSecretName: default-admin-secret
    passwordSecretKey: password

    # Ingress configuration
    ingress:
      ingressClass: <your-ingress-class>  # e.g. alb, nginx
      albAnnotations:
        enabled: false  # Set to true if using AWS ALB
        # sslCertArn: <your-ssl-cert-arn> # Set to the ARN of the SSL certificate for the ingress if using AWS ALB
      sslEnabled: false  # Set to true if managing SSL at the ingress level
      annotations:
        ## when using nginx ingress, add the following annotations to handle large OAuth2 response headers from identity providers
        # nginx.ingress.kubernetes.io/proxy-buffer-size: "16k"
        # nginx.ingress.kubernetes.io/proxy-buffers: "8 16k"
        # nginx.ingress.kubernetes.io/proxy-busy-buffers-size: "32k"
        # nginx.ingress.kubernetes.io/large-client-header-buffers: "4 16k"
        ## when using AWS ALB in addtional to the default alb annotations,
        ## add the following annotations to specify the scheme of the ingress rules
        # alb.ingress.kubernetes.io/scheme: internet-facing # set to internal for private subnet ALB
        # alb.ingress.kubernetes.io/listen-ports: '[{"HTTPS":443}]'
        # alb.ingress.kubernetes.io/ssl-redirect: '443'
    # Resource allocation
    resources:
      requests:
        cpu: "1"
        memory: "1Gi"
      limits:
        memory: "1Gi"

  # Worker service configuration
  worker:
    scaling:
      minReplicas: 1
      maxReplicas: 3
    resources:
      requests:
        cpu: "500m"
        memory: "400Mi"
      limits:
        memory: "800Mi"

  # Logger service configuration
  logger:
    scaling:
      minReplicas: 1
      maxReplicas: 3
    resources:
      requests:
        cpu: "200m"
        memory: "256Mi"
      limits:
        memory: "512Mi"

  # Agent service configuration
  agent:
    scaling:
      minReplicas: 1
      maxReplicas: 1
    resources:
      requests:
        cpu: "100m"
        memory: "128Mi"
      limits:
        memory: "256Mi"

  # Delayed job monitor configuration
  delayedJobMonitor:
    replicas: 1
    resources:
      requests:
        cpu: "200m"
        memory: "512Mi"
      limits:
        memory: "512Mi"

# Sidecar container configurations
sidecars:
  # Global Envoy proxy configuration
  envoy:
    enabled: true
    # Use Kubernetes secrets as reference for the OIDC secrets
    useKubernetesSecrets: true

    # Paths that don't require authentication
    skipAuthPaths:
    - /api/version
    - /api/auth/login
    - /api/auth/keys
    - /api/auth/refresh_token
    - /api/auth/jwt/refresh_token
    - /api/auth/jwt/access_token
    - /client/version

    # Service configuration
    service:
      port: 8000
      hostname: <your-domain>
      address: 127.0.0.1

    # JWT validation: configure providers for your IdP and (if using access tokens) for OSMO-issued tokens
    jwt:
      user_header: x-osmo-user
      providers:
      # Example: Microsoft Entra ID. Add or replace with your IdP (see identity_provider_setup).
      - issuer: https://login.microsoftonline.com/<tenant-id>/v2.0  # (1)
        audience: <client-id>
        jwks_uri: https://login.microsoftonline.com/<tenant-id>/discovery/v2.0/keys
        user_claim: preferred_username
        cluster: idp
      # OSMO-issued JWTs (e.g. for access-token-based access)
      - issuer: osmo
        audience: osmo
        jwks_uri: http://localhost:8000/api/auth/keys
        user_claim: unique_name
        cluster: service


  # OAuth2 Proxy sidecar configuration
  # Set OIDC issuer URL and client ID from your IdP (e.g. Microsoft Entra ID, Google). See identity_provider_setup.
  oauth2Proxy:
    enabled: true
    provider: oidc
    oidcIssuerUrl: https://login.microsoftonline.com/<tenant-id>/v2.0  # (2)
    clientId: <client-id>  # (3)
    cookieDomain: .<your-domain>
    scope: "openid email profile"
    useKubernetesSecrets: true
    secretName: oauth2-proxy-secrets
    clientSecretKey: client_secret
    cookieSecretKey: cookie_secret

  # OpenTelemetry configuration (optional)
  otel:
    enabled: false

  # Rate limiting configuration (optional)
  rateLimit:
    enabled: false
    # Uncomment and configure if using rate limiting
    # redis:
    #   serviceName: <your-redis-host>
    #   port: 6379

  1. Issuer URL from your IdP. See Identity Provider (IdP) Setup for provider-specific values.

  2. OIDC issuer URL from your IdP (same as the JWT issuer).

  3. Client ID from your IdP application registration.

Create router_values.yaml for router with the following sample configurations:

router_values.yaml
# Global configuration shared across router services
global:
  osmoImageLocation: nvcr.io/nvidia/osmo
  osmoImageTag: <version>

  logs:
    enabled: true
    logLevel: DEBUG
    k8sLogLevel: WARNING

# Router service configurations
services:
  # Configuration file service settings
  configFile:
    enabled: true

  # Router service configuration
  service:
    scaling:
      minReplicas: 1
      maxReplicas: 2
    hostname: <your-domain>
    # webserverEnabled: true  # (Optional): Enable for UI port forwarding
    serviceAccountName: router

    # Ingress configuration
    ingress:
      prefix: /
      ingressClass: <your-ingress-class>  # e.g. alb, nginx
      albAnnotations:
        enabled: false  # Set to true if using AWS ALB
        # sslCertArn: arn:aws:acm:us-west-2:XXXXXXXXX:certificate/YYYYYYYY # (Optional): Set to the ARN of the SSL certificate for the ingress if using AWS ALB
      sslEnabled: false  # Set to true if managing SSL at the ingress level
      sslSecret: osmo-tls
      annotations:
        # when using nginx ingress, add the following annotations to handle large OAuth2 response headers from identity providers
        # nginx.ingress.kubernetes.io/proxy-buffer-size: "16k"
        # nginx.ingress.kubernetes.io/proxy-buffers: "8 16k"
        # nginx.ingress.kubernetes.io/proxy-busy-buffers-size: "32k"
        # nginx.ingress.kubernetes.io/large-client-header-buffers: "4 16k"
        ## when using AWS ALB in addtional to the default alb annotations,
        ## add the following annotations to specify the scheme of the ingress rules
        # alb.ingress.kubernetes.io/scheme: internet-facing # set to internal for private subnet ALB
        # alb.ingress.kubernetes.io/listen-ports: '[{"HTTPS":443}]'
        # alb.ingress.kubernetes.io/ssl-redirect: '443'

    # Resource allocation
    resources:
      requests:
        cpu: "500m"
        memory: "512Mi"
      limits:
        memory: "512Mi"

  # PostgreSQL database configuration
  postgres:
    serviceName: <your-postgres-hostname>
    port: 5432
    db: osmo
    user: postgres

# Sidecar container configurations
sidecars:
  # Envoy proxy configuration
  envoy:
    enabled: true
    useKubernetesSecrets: true

    skipAuthPaths:
    - /api/router/version

    image: envoyproxy/envoy:v1.29.0
    imagePullPolicy: IfNotPresent

    # Service configuration
    service:
      hostname: <your-domain>

    # JWT validation: IdP provider(s) and OSMO-issued tokens
    jwt:
      enabled: true
      user_header: x-osmo-user
      providers:
      - issuer: https://login.microsoftonline.com/<tenant-id>/v2.0
        audience: <client-id>
        jwks_uri: https://login.microsoftonline.com/<tenant-id>/discovery/v2.0/keys
        user_claim: preferred_username
        cluster: idp
      - issuer: osmo
        audience: osmo
        jwks_uri: http://osmo-service/api/auth/keys
        user_claim: unique_name
        cluster: osmoauth

    # OSMO auth service configuration
    osmoauth:
      enabled: true
      port: 80
      hostname: <your-domain>
      address: osmo-service

    # (Optional): Enable for UI port forwarding
    # routes:
    # - match:
    #     prefix: "/"
    #   route:
    #     cluster: service
    #     timeout: 0s

  # OAuth2 Proxy sidecar configuration
  oauth2Proxy:
    enabled: true
    provider: oidc
    oidcIssuerUrl: https://login.microsoftonline.com/<tenant-id>/v2.0
    clientId: <client-id>
    cookieDomain: .<your-domain>
    scope: "openid email profile"
    useKubernetesSecrets: true
    secretName: oauth2-proxy-secrets
    clientSecretKey: client_secret
    cookieSecretKey: cookie_secret

Create ui_values.yaml for ui with the following sample configurations:

ui_values.yaml
# Global configuration shared across UI services
global:
  osmoImageLocation: nvcr.io/nvidia/osmo
  osmoImageTag: <version>

# UI service configurations
services:
  # UI service configuration
  ui:
    hostname: <your-domain>

    # Ingress configuration
    ingress:
      prefix: /
      ingressClass: <your-ingress-class>  # e.g. alb, nginx
      albAnnotations:
        enabled: false  # Set to true if using AWS ALB
        # sslCertArn: arn:aws:acm:us-west-2:XXXXXXXXX:certificate/YYYYYYYY # (Optional): Set to the ARN of the SSL certificate for the ingress if using AWS ALB
      sslEnabled: false  # Set to true if managing SSL at the ingress level
      sslSecret: osmo-tls
      annotations:
        # when using nginx ingress, add the following annotations to handle large OAuth2 response headers from identity providers
        # nginx.ingress.kubernetes.io/proxy-buffer-size: "16k"
        # nginx.ingress.kubernetes.io/proxy-buffers: "8 16k"
        # nginx.ingress.kubernetes.io/proxy-busy-buffers-size: "32k"
        # nginx.ingress.kubernetes.io/large-client-header-buffers: "4 16k"
        ## when using AWS ALB in addtional to the default alb annotations,
        ## add the following annotations to specify the scheme of the ingress rules
        # alb.ingress.kubernetes.io/scheme: internet-facing # set to internal for private subnet ALB
        # alb.ingress.kubernetes.io/listen-ports: '[{"HTTPS":443}]'
        # alb.ingress.kubernetes.io/ssl-redirect: '443'

    # Resource allocation
    resources:
      requests:
        cpu: "500m"
        memory: "512Mi"
      limits:
        memory: "512Mi"

sidecars:
  # Envoy proxy configuration
  envoy:
    enabled: true
    useKubernetesSecrets: true

    # Service configuration
    service:
      hostname: <your-domain>
      address: 127.0.0.1
      port: 8000

    # JWT configuration
    jwt:
      user_header: x-osmo-user
      providers:
      - issuer: https://login.microsoftonline.com/<tenant-id>/v2.0
        audience: <client-id>
        jwks_uri: https://login.microsoftonline.com/<tenant-id>/discovery/v2.0/keys
        user_claim: preferred_username
        cluster: idp

  # OAuth2 Proxy sidecar configuration
  oauth2Proxy:
    enabled: true
    provider: oidc
    oidcIssuerUrl: https://login.microsoftonline.com/<tenant-id>/v2.0
    clientId: <client-id>
    cookieDomain: .<your-domain>
    scope: "openid email profile"
    useKubernetesSecrets: true
    secretName: oauth2-proxy-secrets
    clientSecretKey: client_secret
    cookieSecretKey: cookie_secret

Important

Replace all <your-*> placeholders with your actual values before applying. You can find them in the highlighted sections in all the files above.

Note

Refer to the README page for detailed configuration options.

Similar values files should be created for other components (Router, UI) with their specific configurations.

Step 4: Deploy Components#

Deploy the components in the following order:

  1. Deploy API Service:

# add the helm repository
$ helm repo add osmo https://helm.ngc.nvidia.com/nvidia/osmo
$ helm repo update

# deploy the service
$ helm upgrade --install service osmo/service -f ./osmo_values.yaml -n osmo

  1. Deploy Router:

$ helm upgrade --install router osmo/router -f ./router_values.yaml -n osmo

  1. Deploy UI:

$ helm upgrade --install ui osmo/web-ui -f ./ui_values.yaml -n osmo

Step 5: Verify Deployment#

  1. Verify all pods are running:

    $ kubectl get pods -n osmo
NAME                            READY   STATUS    RESTARTS       AGE
osmo-agent-xxx                  2/2     Running   0              <age>
osmo-delayed-job-monitor-xxx    1/1     Running   0              <age>
osmo-logger-xxx                 2/2     Running   0              <age>
osmo-router-xxx                 2/2     Running   0              <age>
osmo-service-xxx                2/2     Running   0              <age>
osmo-ui-xxx                     2/2     Running   0              <age>
osmo-worker-xxx                 1/1     Running   0              <age>

  2. Verify all services are running:

    $ kubectl get services -n osmo
  NAME           TYPE        CLUSTER-IP        EXTERNAL-IP   PORT(S)   AGE
  osmo-agent     ClusterIP   xxx               <none>        80/TCP    <age>
  osmo-logger    ClusterIP   xxx               <none>        80/TCP    <age>
  osmo-router    ClusterIP   xxx               <none>        80/TCP    <age>
  osmo-service   ClusterIP   xxx               <none>        80/TCP    <age>
  osmo-ui        ClusterIP   xxx               <none>        80/TCP    <age>

  3. Verify ingress configuration:

    $ kubectl get ingress -n osmo
NAME           CLASS   HOSTS                          ADDRESS         PORTS     AGE
osmo-agent     nginx   <your-domain>                  <lb-ip>        80, 443    <age>
osmo-logger    nginx   <your-domain>                  <lb-ip>        80, 443    <age>
osmo-router    nginx   <your-domain>                  <lb-ip>        80, 443    <age>
osmo-service   nginx   <your-domain>                  <lb-ip>        80, 443    <age>
osmo-ui        nginx   <your-domain>                  <lb-ip>        80, 443    <age>
osmo-ui-trpc   nginx   <your-domain>                  <lb-ip>        80, 443    <age>

Step 6: Post-deployment Configuration#

  1. Configure DNS records to point to your load balancer. For example, create a record for osmo.example.com to point to the load balancer IP.

  2. Test authentication flow

  3. Configure IdP role mapping to map your IdP groups to OSMO roles: IdP Role Mapping and Sync Modes

  4. Verify access to the UI at https://osmo.example.com through your domain

  5. Create and configure data storage to store service data: Configure Data Storage

Troubleshooting#

  1. Check pod status and logs:

    kubectl get pods -n <namespace>

# check if all pods are running, if not, check the logs for more details
kubectl logs -f <pod-name> -n <namespace>

  2. Common issues and their resolutions:

    • Database connection failures: Verify the database is running and accessible

    • Authentication configuration issues: Verify the authentication configuration is correct

    • Ingress routing problems: Verify the ingress is configured correctly

    • Resource constraints: Verify the resource limits are set correctly

    • Missing secrets or incorrect configurations: Verify the secrets are created correctly and the configurations are correct
