Quickstart
Install sflow
mkdir -p sflow_workspace && cd sflow_workspace
curl -LsSf https://astral.sh/uv/install.sh | sh
uv venv --python python3
source .venv/bin/activate
uv pip install "sflow @ git+https://github.com/NVIDIA/nv-sflow.git@main"
sflow --help
sflow --version # or: sflow -V — print version + runtime/build details
If curl is unavailable (e.g. on some locked-down clusters), install uv via pip instead:
pip install uv
Optional extras enable features that pull in extra dependencies:
pip install 'sflow[s3]' # S3 artifact/result uploads (boto3)
pip install 'sflow[monitor]' # PNG charts for the hardware monitor
One-Minute Mindset
sflow lets you describe a multi-step workflow in a single YAML file and run it on any compute backend — your laptop, a Slurm cluster, a Docker host, or a Kubernetes cluster — without rewriting scripts.
Core ideas:
| Concept | What it does | Example |
|---|---|---|
| Backend | Declares where tasks run. Swap one line to move between local, slurm, docker, and kubernetes. | type: slurm, partition: gpu |
| Operator | Declares how a task's script is launched. Each backend has a default (local → bash, Slurm → srun). Define named operators to preset flags and reuse them across tasks. | type: srun, ntasks: 4 |
| Variable | A named value reusable everywhere — scripts, resource counts, backend config. Override from the CLI with --set. | NUM_GPUS: 8 |
| Task & DAG | Each task is a unit of work with a script. depends_on wires them into a directed graph so sflow runs them in the right order. | depends_on: [train] |
| Probe | A readiness or failure check attached to a task. Downstream tasks wait until the probe passes. Built-ins: TCP port, HTTP endpoint, log pattern match. | type: tcp_port, port: 8080 |
| Resource placement | Topology-aware: sflow assigns nodes and GPUs automatically after allocation, packing tasks contiguously to respect node boundaries. Assigned resources are exposed as variables. | ${{ backends.slurm_cluster.nodes[0].ip_address }} |
Why not just write a bash script? A bash script hard-wires node names, GPU indices, and execution order. With sflow you declare what you want; it handles allocation, node discovery, GPU assignment, dependency ordering, log collection, and retries — the same YAML works locally for debugging and on Slurm for production.
This guide teaches sflow in three parts:
- Part I: Learn the Basics Locally – Write workflows, build DAGs, add variables — no cluster needed
- Part II: Run on Slurm – Take the same config to a real HPC cluster
- Part III: Run on Kubernetes – Take the same config to a Kubernetes cluster
This quickstart covers local, slurm, and kubernetes. The same YAML also runs on the Docker backend — just swap the backend block. See Backends for all four.
Part I: Learn the Basics Locally
Start here to learn sflow concepts without needing a Slurm cluster.
1. Start with a Plain-Text Config
The fastest way to learn sflow is to start with hardcoded values — no variables, no expressions. Get the workflow logic right first.
version: "0.1"
workflow:
name: wf
tasks:
- name: hello
script:
- echo hello
Validate and run:
sflow run --file sflow.yaml --dry-run # validate first
sflow run --file sflow.yaml --tui # run with TUI
Default output structure:
./sflow_output/<run_id>/: per-run root directory./sflow_output/<run_id>/<task_name>/: per-task directory (stdout/stderr go to<task_name>.log)
2. Build a DAG with depends_on
Add multiple tasks and wire them with depends_on. Start with plain text — hardcode everything:
version: "0.1"
workflow:
name: training_pipeline
tasks:
- name: prepare_data
script:
- echo "Downloading cifar10..."
- echo "cifar10" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/dataset.txt
- name: preprocess
depends_on: [prepare_data]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/dataset.txt
- echo "encoded_data ok" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/encoded.txt
- name: train
depends_on: [preprocess]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/encoded.txt
- echo "checkpoint for tiny-transformer" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- name: evaluate_on_dataset1
depends_on: [train]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- echo "accuracy=0.99 dataset=dataset1" > ${SFLOW_TASK_OUTPUT_DIR}/metrics.txt
- name: evaluate_on_dataset2
depends_on: [train]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- echo "accuracy=0.88 dataset=dataset2" > ${SFLOW_TASK_OUTPUT_DIR}/metrics.txt
- name: export_model
depends_on: [evaluate_on_dataset1, evaluate_on_dataset2]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/evaluate_on_dataset1/metrics.txt
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/evaluate_on_dataset2/metrics.txt
- echo "exported tiny-transformer" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/model.onnx
Always validate first, then run:
sflow run --file pipeline.yaml --dry-run
sflow run --file pipeline.yaml --tui
Visualize the DAG without running:
sflow visualize --file pipeline.yaml --format mermaid
3. Extract Variables for Reusability
Once the plain-text config works, identify values that you'd want to change between runs
and extract them into variables. This makes the config reusable without editing the YAML each time.
Before (hardcoded):
- name: train
script:
- echo "checkpoint for tiny-transformer" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
After (parameterized):
variables:
MODEL_NAME:
description: "Model to train"
value: tiny-transformer
workflow:
tasks:
- name: train
script:
- echo "checkpoint for ${MODEL_NAME}" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
Now you can override the value from the CLI without touching the file:
sflow run -f pipeline.yaml --set MODEL_NAME=large-transformer --tui
Variables can be used in two ways:
- In YAML fields (resolved before execution):
${{ variables.MODEL_NAME }} - In scripts (as env var at runtime):
${MODEL_NAME}
Here's the full parameterized version (or get it via sflow sample self_contained/local/dag):
version: "0.1"
variables:
MODEL_NAME:
description: "Model to train"
value: tiny-transformer
workflow:
name: quickstart_dag
tasks:
- name: prepare_data
script:
- echo "prepare_data start"
- echo "model=${{ variables.MODEL_NAME }}" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/dataset.txt
- name: preprocess
depends_on: [prepare_data]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/dataset.txt
- echo "encoded_data ok" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/encoded.txt
- name: train
depends_on: [preprocess]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/encoded.txt
- echo "checkpoint for ${MODEL_NAME}" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- name: evaluate_on_dataset1
depends_on: [train]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- echo "accuracy=0.99 dataset=dataset1" > ${SFLOW_TASK_OUTPUT_DIR}/metrics.txt
- name: evaluate_on_dataset2
depends_on: [train]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/checkpoint.pt
- echo "accuracy=0.88 dataset=dataset2" > ${SFLOW_TASK_OUTPUT_DIR}/metrics.txt
- name: export_model
depends_on: [evaluate_on_dataset1, evaluate_on_dataset2]
script:
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/evaluate_on_dataset1/metrics.txt
- test -f ${SFLOW_WORKFLOW_OUTPUT_DIR}/evaluate_on_dataset2/metrics.txt
- echo "exported ${MODEL_NAME}" > ${SFLOW_WORKFLOW_OUTPUT_DIR}/model.onnx
Plain text first, variables second. Start every new workflow with hardcoded values.
Once it runs successfully, extract the values you want to change into variables.
This makes debugging much easier — you know the recipe works before adding abstraction.
4. Validate Only (Dry-Run)
sflow run --file sflow.yaml --dry-run
Dry-run does not create output directories/files. It prints the execution plan and computed output paths.
5. Explore More Local Capabilities
The local backend is enough to try several sflow features before touching a cluster. Copy any of these with sflow sample <name> (each writes ./<basename>.yaml in the current directory — e.g. sflow sample self_contained/local/result_parsing writes ./result_parsing.yaml):
| Capability | Sample | What it shows |
|---|---|---|
| Result parsing | self_contained/local/result_parsing | Parse metrics from a log/JSON into result.json (see Results) |
| Storage uploads | self_contained/local/storage_upload, self_contained/local/storage_upload_all | Ship logs/results to a storage target such as S3 (see Uploads) |
| Workflow monitor | self_contained/local/monitor | Sample hardware utilization during a run and (optionally) render charts (see Monitor) |
sflow sample self_contained/local/monitor
sflow run -f monitor.yaml
Part II: Slurm Cluster
Take the same workflow concepts to a real HPC cluster. Make sure you have already installed sflow (see Install sflow above).
1. Prepare a Slurm Workflow
How it works (Slurm example):
Start with a plain-text config — hardcode your actual cluster values. No variables yet.
version: "0.1"
backends:
- name: slurm_cluster
type: slurm
default: true
account: "your_slurm_account"
partition: "your_slurm_partition"
time: "00:10:00"
nodes: 1
gpus_per_node: 8
workflow:
name: wf
tasks:
- name: slurm_task
script:
- echo hello
Notes:
- Update
account/partition/time/nodesto match your cluster. - If you're already inside a Slurm allocation,
sflowwill reuse it; otherwise it will callsallocfirst. gpus_per_nodeis used for sflow resource planning and GPU index assignment; it does not add a Slurm allocation flag.- The backend also supports
extra_argsto pass arbitrary flags tosalloc:
backends:
- name: slurm_cluster
type: slurm
default: true
account: "your_slurm_account"
partition: "your_slurm_partition"
time: "01:00:00"
nodes: 2
gpus_per_node: 8
extra_args:
- "--exclusive"
- "--gpus-per-node=8"
- "--segment=8"
Once the plain-text config works, you can extract account, partition, nodes, etc. into variables (same pattern as Part I step 4) to make it reusable across clusters.
You can also use sflow sample to get starter workflows with variables already set up:
sflow sample --list
sflow sample self_contained/slurm/dynamo_trtllm_disagg
2. Operators & srun — How Your Script Actually Runs
On a Slurm backend the default operator is srun. sflow takes your task's script: lines and wraps them into:
srun [flags from operator config] bash -c "<your script lines>"
Operator config fields map directly to srun flags, so you never have to hand-craft srun commands:
| Operator config | srun flag | Purpose |
|---|---|---|
ntasks | --ntasks | Number of task slots |
ntasks_per_node | --ntasks-per-node | Tasks per node |
gpus_per_task | --gpus-per-task | GPUs per task slot |
cpus_per_task | --cpus-per-task | CPU cores per task |
nodes | --nodes | Node count for this step |
container_image | --container-image | Pyxis container (enroot) |
mpi | --mpi | MPI type (e.g. pmix) |
extra_args | (pass-through) | Any other srun flag |
extra_args is a list that passes arbitrary srun flags not covered by the named fields:
operators:
- name: custom_worker
type: srun
ntasks_per_node: 1
extra_args:
- --exclusive
- --mem-per-gpu=80G
- --container-image=nvcr.io/nvidia/pytorch:24.05-py3
- --container-mounts=/data:/data:ro
You can define named operators once and reference them by name in tasks — or override individual fields per task:
operators:
- name: gpu_worker
type: srun
ntasks_per_node: 1
gpus_per_task: 1
container_image: nvcr.io/nvidia/pytorch:24.05-py3
workflow:
tasks:
- name: train
operator: gpu_worker # uses the preset above
script:
- torchrun train.py
- name: inference
operator: # inline override
name: gpu_worker
ntasks: 8 # override just this field
script:
- python infer.py
Without sflow, the equivalent train task would require you to manually write:
srun --jobid=$SLURM_JOB_ID --nodes=1 --ntasks-per-node=1 --gpus-per-task=1 \
--container-image=nvcr.io/nvidia/pytorch:24.05-py3 \
bash -c "torchrun train.py"
sflow builds this command for you from the declarative config.
3. Run on Slurm (Interactive)
Before running, make sure you have updated the workflow YAML for your environment:
- Slurm settings: set
accountandpartitionto values valid on your cluster - Model paths: update any model or data paths to locations accessible from your compute nodes
- Container images: if the workflow uses a container operator, update the image tag to the version you need
- Extra args: Some clusters require
--gpus-per-nodewhen requesting GPU partitions. Add it explicitly in backendextra_args; sflow does not infer or add that Slurm flag fromgpus_per_node.
Validate first with a dry-run to catch config errors without allocating nodes:
sflow run --file sflow.yaml --dry-run
Once validation passes, launch the workflow:
sflow run --file sflow.yaml --tui
The TUI shows:
- Left: task status table + backend allocation summary
- Right: auto-tail logs (timestamp + level + module/logger)

For headless mode (automated jobs), run without --tui:
sflow run --file sflow.yaml
If your workflow pulls images from a private registry (e.g. nvcr.io), you need to configure enroot credentials on the cluster before running. Create or edit ~/.config/enroot/.credentials:
machine nvcr.io login $oauthtoken password <your-ngc-api-key>
Replace the machine/credentials for whichever registry your images come from. Without this file, srun --container-image will fail to pull private images.
4. Batch Mode: Fire-and-Forget Slurm Jobs
For long-running or production workflows, sflow batch generates a complete sbatch script with proper environment setup and job submission. This is the recommended way to run production workloads.
Why Use Batch Mode?
- Fire-and-forget: Submit the job and disconnect; it runs headlessly
- Automatic environment setup: Creates/activates a Python venv on compute nodes, this solves the python and lib difference often seen in clusters (e.g., login vs compute nodes)
- Dry-run validation: Validates the workflow before running to fail early
- Portable scripts: Generated scripts can be saved, reviewed, and resubmitted
Basic Usage
Generate an sbatch script to stdout:
sflow batch --file workflow.yaml
Save to a file:
sflow batch --file workflow.yaml --sbatch-path run_workflow.sh
Generate and submit immediately:
sflow batch --file workflow.yaml --sbatch-path run_workflow.sh --submit
Add extra slurm flags if required when submitting jobs in some cluster:
sflow batch --file workflow.yaml --sbatch-path run_workflow.sh -e '--exclusive' -e '--gpus-per-node=8' -e '--segment=8'
Full Example with Slurm Options
sflow batch \
--file sglang_server_client.yaml \
--partition gpu \
--account myaccount \
--time 02:00:00 \
--nodes 2 \
--gpus-per-node 4 \
--job-name my-inference-job \
--sbatch-path run_inference.sh \
--submit
Note:
--gpus-per-node(-G) sets the cluster topology for sflow's resource planning (default: 4). It does NOT add a#SBATCH --gpus-per-nodedirective. If your cluster requires that directive, add it via-e '--gpus-per-node=4'.
With Variable Overrides
Override workflow variables at submission time:
sflow batch \
--file workflow.yaml \
--set NUM_GPUS=8 \
--set MODEL_NAME=llama-70b \
--sbatch-path run.sh
Per-Job Virtual Environment
By default each Slurm job creates its own fresh, disposable venv on the compute node
(.sflow_venv-<job id>/) using the node's system python3, so it always matches the node
architecture (e.g. x86 login node vs arm64 compute node) and is removed when the job exits.
Pass --sflow-venv-path to change the parent directory it is created under (e.g. a
shared-filesystem path instead of node-local scratch):
sflow batch \
--file workflow.yaml \
--sflow-venv-path /shared/scratch/sflow-venvs \
--sbatch-path run.sh
What the Generated Script Does
- Sets sbatch directives: job name, output/error files, partition, account, time limit
- Creates a fresh per-job venv: builds
.sflow_venv-<job id>/on the compute node with sflow installed, then removes it on exit (override the parent dir with--sflow-venv-path) - Runs dry-run validation: Catches configuration errors before the full run
- Executes the workflow: Runs
sflow runwith all provided options
Common Options
| Option | Description |
|---|---|
--file, -f | Path to the sflow.yaml workflow file |
--sbatch-path, -o | Write sbatch script to file (required for --submit) |
--submit | Submit the job immediately after generating |
--partition, -p | Slurm partition |
--account, -A | Slurm account |
--time | Time limit (e.g., 02:00:00) |
--nodes, -N | Number of nodes for the sbatch job |
--gpus-per-node, -G | Number of GPUs per node |
--job-name, -J | Slurm job name (default: sflow) |
--set, -s | Override variable (can be repeated) |
--artifact, -a | Override artifact URI (can be repeated) |
--sflow-venv-path | Parent dir for the fresh per-job venv (default: compute-node-local scratch) |
Monitoring Batch Jobs
After submission, monitor your job with standard Slurm commands:
squeue -u $USER # Check job status
scancel <job_id> # Cancel a job
tail -f sflow_output/sflow-<job_id>.out # Follow output logs
Part III: Kubernetes Cluster
Run the same workflow concepts on a Kubernetes cluster. Make sure you have already installed sflow (see Install sflow above), and that the machine running sflow has working cluster access — sflow shells out to your local kubectl.
How it works (Kubernetes example):
A few things differ from Slurm on the Kubernetes backend today:
sflow runis interactive (attached) only — there is nosflow batch/ fire-and-forget mode on K8S yet, so the driver process must stay connected for the whole run.monitor:blocks are skipped (no in-cluster hardware collector yet).- Tested on vanilla bare-metal Kubernetes and Google GKE; other environments are untested.
1. Prepare a Kubernetes Workflow
Two things differ from the Slurm setup:
- The workload image lives on the operator, not the backend. The
kubernetesbackend declares where (namespace, nodes, GPUs); the operator declares the containerimageto run. - There is no default operator on Kubernetes. Unlike
local→bashorslurm→srun, every K8S task must name an explicitk8s(ork8s_mpi) operator that carries animage.
Start with the smallest working recipe — CPU-only (gpus_per_node: 0). Grab it with sflow sample self_contained/kubernetes/hello_world:
version: "0.1"
backends:
- name: k8s
type: kubernetes
default: true
namespace: default
nodes: 1
gpus_per_node: 0
operators:
- name: k8s_op
type: k8s
image: ubuntu:22.04 # the workload image lives on the operator
workflow:
name: kubernetes_hello_world
tasks:
- name: hello
operator: k8s_op
script:
- echo "Hello from Kubernetes"
Common backend fields:
| Backend field | Default | Purpose |
|---|---|---|
namespace | — | Namespace to run in; must already exist. One namespace per backend (use separate backends for separate namespaces). |
nodes | — | Number of nodes to reserve for the workflow. |
gpus_per_node | derived from node capacity | GPUs per node; checked against real GPU capacity at pre-flight. Set 0 for CPU-only. |
scheduling | device_plugin | How GPUs are requested: device_plugin (NVIDIA gpu-operator, nvidia.com/gpu) or dra (K8s 1.34+, WIP). |
gpu_resource_name | nvidia.com/gpu | Override the device-plugin resource name (e.g. MIG nvidia.com/mig-1g.5gb). |
host_network | true | Pod shares the node network namespace (pod IP == node IP). Privileged; turn off on CNI-routable clusters. |
host_ipc | false | Share the node IPC namespace + /dev/shm for cross-pod CUDA IPC over NVLink. Privileged; opt-in. |
volumes | — | Mount existing PVCs / emptyDir scratch into every task pod. PVCs must already exist — sflow references them, it does not create them. |
See Backends for the full field list, including DRA/MIG, RDMA, and Multi-Node NVLink options.
2. Operators on Kubernetes
Each task's script: lines run inside a pod built from the operator's container image. There are two K8S operator types:
| Operator | Use for |
|---|---|
k8s | Standard single/multi-node container tasks. Required field: image. |
k8s_mpi | mpirun-launched workloads — inherits every k8s field and adds an mpi: block; sflow injects the SSH/hostfile/sshd glue for you. |
Frequently-used k8s operator fields:
| Operator field | Default | Purpose |
|---|---|---|
image | (required) | Container image for the task's pod. |
image_pull_secrets | — | Secret name(s) for pulling from a private registry (e.g. nvcr.io). |
service_account | — | Pod service account (RBAC / cloud workload identity). |
run_as_root | false | Run the container as root. |
shm_size | node RAM | Shared-memory (/dev/shm) size. The K8s 64Mi default segfaults multi-GPU NCCL/MPI jobs — set e.g. 64Gi. |
cpu / memory | — | Resource requests (cpu_limit / memory_limit set limits). |
env | — | Extra environment variables for the pod. |
You can define named operators once and reference them by name in tasks, or override fields per task — the same pattern shown for Slurm operators in Part II.
3. Connect to the Cluster and Run
Cluster credentials are passed as CLI flags on sflow run, never in the YAML — so the same recipe stays cluster-agnostic:
| Flag | Default |
|---|---|
--kubeconfig PATH | $KUBECONFIG, else ~/.kube/config |
--kube-context NAME | current context |
--kube-namespace NAME | the backend's namespace |
Validate first with a dry-run to catch config errors without touching the cluster:
sflow run --file hello_world.yaml --dry-run
Then run against your cluster (add --tui for the live status/log view):
sflow run -f hello_world.yaml \
--kubeconfig ~/.kube/prod.config \
--kube-context prod-east \
--kube-namespace ml-team \
--tui
Before allocating, sflow runs a non-mutating RBAC pre-flight (kubectl auth can-i …) for the pod/configmap/secret/log operations it needs and fails fast with an actionable message if a permission is missing. Bypass it with SFLOW_SKIP_K8S_PREFLIGHT=1 if your cluster restricts auth can-i.
Prerequisites:
- Working
kubectlaccess from the machine running sflow. - The target namespace already exists, with RBAC to create/delete pods, configmaps, and secrets and to read pod logs and nodes.
- For GPUs: the NVIDIA gpu-operator installed (
device_plugin, the default), or K8s 1.34+ withnvidia-dra-driver-gpu(dra, WIP). - Any PVCs referenced under
volumes:already exist in the namespace. For quick debugging on a cluster that lacks them,sflow run --kube-skip-pvcdrops PVC-backed volumes.
For images from a private registry (e.g. nvcr.io), create a Kubernetes pull secret in your namespace and reference it from the operator:
kubectl create secret docker-registry ngc-secret \
--docker-server=nvcr.io \
--docker-username='$oauthtoken' \
--docker-password=<your-ngc-api-key> \
-n ml-team
operators:
- name: gpu_worker
type: k8s
image: nvcr.io/nvidia/pytorch:24.05-py3
image_pull_secrets: [ngc-secret]
4. A Real GPU Workload
For a full disaggregated LLM-serving deployment, grab the packaged sample:
sflow sample self_contained/kubernetes/dynamo_trtllm_disagg
It shows a 3-node, 8-GPU-per-node backend with host_network, host_ipc (cross-pod CUDA IPC over NVLink), RDMA, and a read-only model PVC — wired to a k8s_mpi operator for the prefill/decode servers and plain k8s operators for the NATS/etcd/frontend infra and the benchmark client. Browse all Kubernetes starters with:
sflow sample --list
